Item |
KC4520 |
Grinding Part Diameter(mm) |
Φ1.6~φ50 |
Continuous Grinding(mm) |
Standard Bracket250 |
Plunge Feed 200 |
Abrasion Wheel Size(mm) |
P455×205×203.2 |
Guide Wheel Size(mm) |
P305×205×177.8 |
Abrasion Wheel Rotate Speed(r/min) |
1900 |
Guide Wheel Rotate Speed(r/min) |
12~230 AC frequency Conversion Infinitely Adjustable-Speed |
Guide Wheel Rotation Angel |
In Vertical Plane |
-5° ~ 5° |
In Horizontal Plane |
-1° ~ 3° |
Length from Abrasion Wheel and the centre of Grinding Wheel to the underside of Bracket(mm) |
225 |
Length from Abrasion Wheel and the centre of Grinding Wheel to the underside of Bed(mm) |
1040 |
Minimum feed of Abrasion Wheel Dresser((mm) |
0.001 |
Minimum Load(mm) |
0.001 |
Abrasion Wheel Motor Power (kW) |
11 4P |
Grinding Wheel Motor Power(kW) |
1.5 6P |
Water Pump Motor Power(kW) |
0.12 2P |
Magnetic Power Motor Power (kW) |
0.18 |
Torque Capacity of Grinding Wheel Feed Servo Motor(N.m) |
10.9 |
Torque Capacity of Abrasion Wheel Dresser Feed Servo Motor(N.m) |
5.2 |
Torque Capacity of Grinding Wheel Dresser Feed Servo Motor(N.m) |
7.2 |
Cooling Water Flux(L/min) |
|
Machine Power Supply |
3N ~50Hz,380V |
Machine Weight(t) |
6 |
Machine Size (L×W) |
|
